Mini LED

Material formula, high masking performance, and optical and structural design
◆ DP technology
As one of the top 3 diffuser manufacturers in the world, Entire has accrued abundant experience in the display application market through a combination of composite DP technology as well as optical and structural design.

From formula design, kneading and granulation, extrusion, to cutting, and packaging, we are able to provide our clients with premium optical materials.
Features and advantages
Features Advantages
Material formula Proprietary formula improves PC's UV-resistance
Structural design 2-dimensional microstructure design, excellent diffraction performance
High diffusivity Effectively masks LED with different transmittance to achieve highly balanced lighting.
High masking
performance		 Unique foam extrusion technology increases masking performance through the differences in the air refractive index.
Excellent
weather-resistance		 Heat-resistant PC material.
Product specifications and applications
Material Model Thickness Transmittance Product features Product Applications
PC ECD-PXXM 1.0mm 70% • Suitable for w/o 2nd Lens backlight
• Increasing luminous efficacy by 5%
• Can be stacked in layers		 Applicable to various Mini LED backlight modules
ECD-PXXD 0.25~1.0mm 70~95% • Suitable for w/o 2nd Lens backlight
• Excellent diffraction performance and luminous efficacy
• Can be stacked in layers
Customized specifications available,
please contact us for further details.
