5G material
穎台科技股份有限公司 - 創造企業競爭力與穩固全球光電材料 technology的領導者

5G material

Unique materials, co-extrusion production, and high heat-resistance
◆ Composite plate technology
As a professional optical composite plate manufacturer, Entire offers one-stop production from formula design, kneading, granulation to composite material extrusion, cutting, and polishing. We also support customized formula design, providing our clients with the highest-quality composite 5G material.
Features and advantages
Features Advantages
Co-extrusion
production process		 Multiple layer material extrusion
High hardness PMMA layer offers high hardness and scratch-resistance
High strength PC layer offers high heat-resistance and high strength
Product specifications and applications
Material Material
thickness		 Product Applications
PC / PMMA 0.64 / 0.8 mm 5G application, consumer electronics case
Composite plate series
Type Model
EFP
 Thickness
(mm)
 PMMA layer
thickness
(um)
 Impact
resistance		 Weather
resistance		 PC-UVA PMMA
-UVA		 Product property
Normal 15E 0.64/0.8 45 OO O V V • Apply to rear
  cover 3D forming
• Drop Ball Test
  60g / 30cm PASS
15F 55 O O V V
18E 45 OO O- X V
18F 55 O O- X V
High
UV-resistance		 19F 0.64/0.8 55 O OO X V PMMA layer
T.t. 380nm < 1%
High
impact-resistance		 39F 0.64/0.8 55 OOO OO X V Drop Ball Test
60g / 120cm PASS
Customized specifications available,
please contact us for further details.
